AUTOMATIC WAREHOUSES
FULL AUTOMATION
AUTOMATED WAREHOUSES IMPROVE THE ENTIRE STORAGE AND PICKING PROCESS, REDUCING HUMAN INTERVENTION AND MINIMIZING ERRORS. THIS APPROACH ENSURES EFFICIENT AND PRECISE MANAGEMENT OF YOUR PRODUCTS.
HIGH STORAGE DENSITY
THANKS TO THEIR COMPACT DESIGN, THESE SYSTEMS ALLOW YOU TO MAXIMIZE THE USE OF AVAILABLE SPACE.
QUICK ACCESS AND WITHDRAWAL
WAREHOUSE HANDLING AND MANAGEMENT TECHNOLOGY ALLOWS RAPID ACCESS TO PRODUCTS AND EFFECTIVE SPEED UP OF PICK-UP OPERATIONS. THIS TRANSLATES INTO HIGHER PRODUCTION SPEED AND REDUCED WAITING TIMES.
WAREHOUSE CATALOGUE
LINEAR WAREHOUSES
CHAIN
AUTOMATIC WAREHOUSE WITH TRAY TRANSPORT ON 1-AXIS CONTROLLED CHAIN.
TRAY FORMAT:
• 400X600 MM;
• 800X600 MM;
• 1200X800 MM.
SPECIAL VERSIONS ON REQUEST
ART VISION
AUTOMATIC WAREHOUSE WITH MOTORIZED CONVEYOR EQUIPPED WITH TRANSLUCENT AND BACKLIT BELT.
IDEAL FOR APPLICATIONS WITH ARTIFICIAL VISION SYSTEMS.
TABLE-TOP
FLEXIBLE AUTOMATIC WAREHOUSE WITH RECIRCULATION CONVEYOR OF FREE PALLETS IN ACCUMULATION.
EQUIPMENT: STOPPERS, DOSING DEVICES, EXHAUSTS, LIFTS, TILTERS AND MUCH MORE
CYL
AUTOMATIC WAREHOUSE FOR CYLINDRICAL PIECES.
MOTORIZED DOUBLE CHAIN CONVEYOR AND V-SHAPED HOUSINGS.
SELF-CENTRING CHAIN OPENING ACCORDING TO PIECE LENGTH
TRANSTORE
AUTOMATIC WAREHOUSE WITH THREE CONTROLLED AXES, SPECIFIC FOR CYLINDRICAL PIECES.
STABILISES EQUIPPED WITH SELF-CENTERING SYSTEM
STACK HEIGHT 500 MM
2 VERSIONS:
• 14 STACKS
• 20 STACKS
AUTOMATIC TRAY WAREHOUSES
CP 5060
POWERED BY TROLLIES, TROLLIES DIMENSION 550X500 MM
SUITABLE FOR ANY TYPE OF ROBOT
CP 5080
FEEDING VIA SIDE BY SIDE TRAYS, TRAY SIZE 750X500 MM
SUITABLE FOR ANY TYPE OF ROBOT
CP 02
2 CONTROLLED AXES, CAPACITY 1 STACK OF TRAYS
- 2 VERSIONS -
• STACK HEIGHT 700 MM
• STACK HEIGHT 1000 MM
TRAY SIZE
• 400X600 MM
• 600X800 MM
CP 03
2 CONTROLLED AXES, CAPACITY 2 STACKS OF TRAYS
- 2 VERSIONS -
• STACK HEIGHT 700 MM
• STACK HEIGHT 1000 MM
TRAY SIZE
• 400X600 MM
• 600X800 MM
AUTOMATIC ROTARY WAREHOUSES - ROTOPALLET SERIES
ROTOPALLET 2
N°1 CONTROLLED AXIS
CAPACITY N°2 TRAY STATIONS
TRAY FORMAT
400X600MM, 800X600MM,
1200X800 MM
SPECIAL VERSIONS ON REQUEST
ROTOPALLET 4
N°1 CONTROLLED AXIS
CAPACITY N°4 TRAY STATIONS
TRAY SIZE
400X600 MM
SPECIAL VERSIONS ON REQUEST
ROTOSTORE
AUTOMATIC WAREHOUSE FOR "DISC" TYPE PIECES WITH STATIONS EQUIPPED WITH SELF-CENTRING SYSTEM AND STACK HEIGHT OF 500 MM.
PIECE MANAGEMENT FROM Ø 40 TO Ø 256 MM
2 VERSIONS
10 STACKS, 18 STACKS
